Download MendeleyX-ray Structure of YB61_HAEIN Northeast Structural Genomics Consortium Target IR63.
Kuzin, A.P., Lee, I., Chiang, Y., Acton, T.B., Montelione, G.T., Hunt, J.F., Tong, L.To be published.
1SC0 | pdb_00001sc0
X-ray Structure of YB61_HAEIN Northeast Structural Genomics Consortium Target IR63
- PDB DOI: https://doi.org/10.2210/pdb1SC0/pdb
- Entry: 1SC0 supersedes: 1O0I
- Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
- Organism(s): Haemophilus influenzae
- Expression System: Escherichia coli BL21(DE3)
- Mutation(s): Yes
- Deposited: 2004-02-11 Released: 2004-03-30
Experimental Data Snapshot
- Method: X-RAY DIFFRACTION
- Resolution: 1.70 Å
- R-Value Free: 0.236 (Depositor), 0.252 (DCC)
- R-Value Work: 0.203 (Depositor), 0.216 (DCC)
- R-Value Observed: 0.203 (Depositor)
wwPDB Validation 3D Report Full Report
This is version 1.3 of the entry. See complete history.
Literature
To be published.
Macromolecules
Find similar proteins by:
(by identity cutoff) | 3D Structure
Entity ID: 1 | |||||
|---|---|---|---|---|---|
| Molecule | Chains | Sequence Length | Organism | Details | Image |
| Hypothetical protein HI1161 | 138 | Haemophilus influenzae | Mutation(s): 3 Gene Names: HI1161 EC: 3.1.2 |  | |
UniProt | |||||
Find proteins for P45083 (Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd)) Explore P45083 Go to UniProtKB: P45083 | |||||
Entity Groups | |||||
| Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
| UniProt Group | P45083 | ||||
Sequence AnnotationsExpand | |||||
| |||||
Small Molecules
| Modified Residues 1 Unique | |||||
|---|---|---|---|---|---|
| ID | Chains | Type | Formula | 2D Diagram | Parent |
| MSE Query on MSE | A, B | L-PEPTIDE LINKING | C5 H11 N O2 Se |  | MET |
Experimental Data & Validation
Experimental Data
- Method: X-RAY DIFFRACTION
- Resolution: 1.70 Å
- R-Value Free: 0.236 (Depositor), 0.252 (DCC)
- R-Value Work: 0.203 (Depositor), 0.216 (DCC)
- R-Value Observed: 0.203 (Depositor)
Space Group: C 1 2 1
Unit Cell:
| Length ( Å ) | Angle ( ˚ ) |
|---|---|
| a = 99.5 | α = 90 |
| b = 60.9 | β = 134.5 |
| c = 70.96 | γ = 90 |
| Software Name | Purpose |
|---|---|
| DENZO | data reduction |
| SCALEPACK | data scaling |
| SOLVE | phasing |
| CNS | refinement |
Entry History
Deposition Data
- Released Date: 2004-03-30 Deposition Author(s): Kuzin, A.P., Lee, I., Chiang, Y., Acton, T.B., Montelione, G.T., Hunt, J.F., Tong, L., Northeast Structural Genomics Consortium (NESG)
- This entry supersedes: 1O0I
Revision History (Full details and data files)
- Version 1.0: 2004-03-30
Type: Initial release - Version 1.1: 2008-04-29
Changes: Version format compliance - Version 1.2: 2011-07-13
Changes: Version format compliance - Version 1.3: 2024-11-20
Changes: Data collection, Database references, Derived calculations, Structure summary
